Specifications |
Thread |
OD |
Length |
Thread |
OD |
Length |
2 7/8 EUE Pin |
3.15 |
8.66 |
2 7/8 EUE Box |
3.15 |
8.66 |
2 3/8 REG Pin |
3.15 |
7.48 |
2 3/8 REG Box |
4.33 |
7.87 |
3 1/2 REG Pin |
3.94 |
8.66 |
3 1/2 REG Box |
5.12 |
10.63 |
4 1/2 REG Pin |
5.71 |
10.24 |
4 1/2 REG Box |
6.3 |
10.24 |
6 5/8 REG Pin |
7.48 |
11.02 |
6 5/8 REG Box |
7.87 |
11.02 |
7 5/8 REG Pin |
8.27 |
11.42 |
7 5/8 REG Box |
9.06 |
11.42 |
NC26 Pin |
3.5 |
7.87 |
NC26 Box |
4.33 |
7.87 |
NC31 Pin |
3.94 |
8.23 |
NC31 Box |
4.72 |
8.66 |
NC38 Pin |
4.53 |
10.24 |
NC38 Box |
4.72 |
10.63 |
NC46 Pin |
5.91 |
10.63 |
NC46 Box |
6.3 |
10.24 |
NC50 Pin |
6.1 |
10.63 |
NC50 Box |
6.3 |
10.24 |
|
